Description
Key Specifications
Network Interfaces
GPON NNI (Network-to-Network Interface): SC/UPC optical interface compliant with Class B+.
User Network Interface (UNI):
4 FE Ports: Auto-negotiation Ethernet ports for seamless wired connectivity.
Wi-Fi Access Point: IEEE 802.11b/g/n with 2 × 2 MIMO technology, offering stable wireless speeds.
USB Port: For file sharing or other USB-related functionalities.
Performance
Wi-Fi Antenna Gain: 2dBi, ensuring adequate wireless coverage.
L2 Forwarding Capability:
Downstream: 2 Gbit/s.
Upstream: 1 Gbit/s.
IPv4 L3 Forwarding Capability:
Downstream: 2 Gbit/s.
Upstream: 1 Gbit/s.
IPv6 L3 Forwarding Capability:
500 Mbit/s (for versions V300R013C00 to V300R015C00).
2 Gbit/s (for V300R015C10 and later versions).
Maximum MAC Addresses Learned: 1024.
Design and Power
Dimensions: 156mm × 125mm × 30mm (W × D × H).
Power Supply:
11-14V DC, 1A.
Input Power: 150V–264V AC, 50/60Hz.
Cooling: Passive cooling ensures silent operation.
Operating Conditions
Temperature Range: 0°C to +40°C.
Humidity Range: 5%–95% (non-condensing).
Main Features
GPON Technology:
Supports high-bandwidth access and ensures robust performance for applications like high-definition video streaming, online gaming, and VoIP.
Versatile UNI Ports:
Provides flexibility with 4 Ethernet ports, Wi-Fi, and a USB interface for enhanced usability.
Advanced Forwarding Capabilities:
With Layer 2 and Layer 3 forwarding speeds of up to 2 Gbit/s, the device supports a wide range of applications, including IPv4 and IPv6 environments.
Passive Cooling:
Operates silently, making it ideal for home and office use.
Compact and Lightweight:
Small dimensions and lightweight build allow for easy installation and placement in limited spaces.
Energy Efficient:
Consumes minimal power, reducing operating costs while ensuring performance.
Applications of the Huawei HG8145C
Home Networks:
Ideal for households requiring high-speed internet, VoIP, and HD video streaming.
Small Office/Home Office (SOHO):
Supports reliable and scalable networking for small businesses.
Smart Home Integration:
Seamlessly connects smart devices like IP cameras, smart TVs, and IoT systems.
Features
Brand : No Brand
SKU : (View phone number)_PK(View phone number)
Express delivery : Islamabad
Condition : Daraz Like New
Graphics Memory : Rapid Memory
Ports : 6
Number Cpus : Superior Chip for Enhanced Performance
Model : HG8145C onu
