Usage Instructions
Select the correct voltage and connector for the electronic device you wish to charge or power.
Press the switch to initiate charging once your device is connected to the power bank. If you disconnect the cable, the device will enter auto-sleep mode after one minute.
During charging, five LED lights will flash in sequence, and all lights will remain lit once your device is fully charged.
If you wish to use the LED light function, press the switch for five seconds to turn it on. You can cycle through the light modes (light, strobe, SOS, off) by pressing the switch again.
Store the jump starter in a cool, dry location away from direct sunlight.
Safety Precautions
Please observe the following safety precautions:
- Do not alter the operation sequence of the jump starter.
- Avoid using the jump starter if the battery indicator shows fewer than three lights to prevent damage to the unit.
- Remove the product from the vehicle within 30 seconds after starting to avoid potential security risks.
Specifications
- Output: 12V
- USB Output: 5V-2A
- Charge Mode: CC/CV 13.5V-1A
- Start Current: 300A
- Peak Current: 600A (3S)
- Cycle Life: 3000 times
- Operating Temperature Range: -20 to 60 Celsius
